4.DESCRIPTION OF PARAMETERS B-63530EN/03

- 66 -

1260 Amount of a shift per one rotation of a rotary axis

NOTE

When this parameter is set, the power must be

turned off before operation is continued.

[Data type] 2-word axis

[Unit of data]

IS-A IS-B IS-C

Unit of data

0.01 deg 0.001 deg 0.0001 deg

Standard value

36000 deg 360000 deg 3600000 deg

[Valid data range] 1000 to 99999999

Set the amount of a shift per one rotation of a rotary axis.

For the rotary axis used for cylindrical interpolation, set the standard

value.

1280

First address of the signal group used by the external machine zero point

shift extension

[Data type] Word

[Valid data range] 0 to 65535

Set the first address of the signal group used by the external machine

zero point shift extension. If 100 is specified, R0100 to R0115 can be

used.

R0100

Shift amount of external machine zero point shift extension for the

first axis (LOW)

R0101

Shift amount of external machine zero point shift extension for the

first axis (HIGH)

R0102

Shift amount of external machine zero point shift extension for the

second axis (LOW)

R0103

Shift amount of external machine zero point shift extension for the

second axis (HIGH)

: :

R0114

Shift amount of external machine zero point shift extension for the

eighth axis (LOW)

R0115

Shift amount of external machine zero point shift extension for the

eighth axis (HIGH)

NOTE

1 If the specified number is not present, the external

machine zero point shift extension is disabled.

2 A shift amount of the external machine zero point

shift extension can be written from the C executer

or macro executer.

3 This parameter is valid when bit 0 (EMC) of

parameter No. 1203 is set to 1.
