B-63530EN/03 4.DESCRIPTION OF PARAMETERS

- 241 -

3410 Tolerance of arc radius

[Data type] 2-word

[Unit of data]

Input increment IS-A IS-B IS-C Unit

Metric input 0.01 0.001 0.0001 mm

Inch input 0.001 0.0001 0.00001 inch

[Valid data range] 1 to 99999999

When a circular interpolation command (G02, G03) is executed, the

tolerance for the radius between the start point and the end point is set.

If the difference of radii between the start point and the end point

exceeds the tolerance set here, a P/S alarm No.20 is informed.

NOTE

When the set value is 0, the difference of radii is

not checked. In the HPCC mode, a check is made

for a difference in the arc radius even if the set

value is "0" (with allowable limit = 0).

3411 M code preventing buffering 1

3412 M code preventing buffering 2

3413 M code preventing buffering 3

: :

3420 M code preventing buffering 10

[Data type] 2-word

[Valid data range] 0 to 255

Set M codes that prevent buffering the following blocks. If processing

directed by an M code must be performed by the machine without

buffering the following block, specify the M code.

M00, M01, M02, and M30 always prevent buffering even when they

are not specified in these parameters.
