Open CNC (Ladder Editing Package, Windows) Operators manual Page 137

Operators manual
B-63484EN/05 3.CREATING AND EDITING SEQUENCE PROGRAMS
- 109 -
Summary of step sequence program edit screen
Fig. 3.4 (b)
Zoom-out button
Reduces the step ladder screen display.
Zoom-in button
Magnifies the step ladder screen display.
Search button
Searches for a step number and action.
Address display method selection button
Switches between address and symbol displays.
Check button
Check program syntax.
Information about element in the cursor position
Displays a step number, action (subprogram), and label number.
Cursor position
Displays the row and column of the current cursor position.
Step sequence program name
A
ddress display method selection button
Check button
Zoom-in button
Zoom-out button
Curso
r
Cursor position
Search button
Information about element in cursor position
Previous page
Next page
