B-63484EN/05 APPENDIX D.MULTI-LANGUAGE PMC MESSAGE CREATION TOOL

- 431 -

D.2 USAGE

This section describes the usage of multi-language PMC message

creation tool.

This tool is included in the installation disk of Ladder Editing Package

(Windows). But this tool can be executed by command line, so that

the process of generating the file can be automated by batch

command.

1) Creating a memory card format file of multi-language PMC

message file from source files.

Fmsgcnv [drive:][path]

message-file1

[+ [drive:][path]

message-file2

] [+ …]

[/m=[drive:][path]

lad-mcard-file

]

[/l=[drive:][path]

lad-file

]

[/p=

pmc-path-number

]

/o=[drive:][path]

mcard-file

Parameter

[drive:][path]

message-file1,

[drive:][path]

message-file2, …

Specify the location and name of a multi-language message file.

Two or more multi-language message files can be specified by using +.

When only the file name is specified, the multi-language message file is

considered to be on current folder.

/m=[drive:][path]

lad-mcard-file

To confirm the multi-language message not correctly displayed, please specify

this parameter.

In lad-mcard-file, specify the name of a sequence program (memory card

format file) related to source files.

When only the file name is specified,

lad-mcard-file

is considered to be on current

folder.

This parameter can be omitted.

/l=[drive:][path]

lad-file

To confirm the multi-language PMC message not correctly displayed, please specify

this parameter.

In lad-file, specify the name of .LAD file related to source files.

When only the file name is specified,

lad-file

is considered to be on current folder.

This parameter can be omitted.

Please do not execute this tool while the .LAD file specified by /l paramete

has been opened by FANUC LADDER-III.

/p=pmc-path-number (1=1st-path PMC, 2=2nd-path PMC, 3=3rd-path PMC)

Specify the pmc path number of the separated message file.

When this parameter is omitted, multi-language PMC message file of 1st-path

PMC is created.

/O=[drive:][path]

mcard-file

Specify the location and name of a multi-language PMC message file.

When only the file name is specified, a multi-language PMC message file is created

on current folder.
