B-63484EN/05 SAFETY PRECAUTIONS

s-3

1.2 WARNINGS AND NOTES RELATING TO LADDER

EDITING PACKAGE (Windows)

Warnings and notes relating to Ladder Editing Package (Windows)

appear in this manual. Before using the software, read this manual

thoroughly and take time to read the Warnings, Cautions, and Notes in

this manual carefully.

In addition, "READ THE FOLLOWING:" which appears in the next

section, summarizes the note to be kept in mind when Ladder Editing

Package (Windows) is used, which is not described in the chapters in

this manual. Before using this software, also read this part.

1.3 READ THE FOLLOWING:…

The following summarizes the points that the user should keep in

mind when using Ladder Editing Package (Windows). Before using

Ladder Editing Package (Windows), read the following:

CAUTION

In this manual we have tried as much as possible

to describe all the various matters.

However, we cannot describe all the matters which

must not be done, or which cannot be done,

because there are so many possibilities.

Therefore, matters which are not especially

described as possible in this manual should be

regarded as “impossible”
