12.ERROR MESSAGES B-63484EN/05
- 408 -
Error code Message Cause/action
K: W-7019 Address and Symbol type is undefined. Confirm the type of the address and the symbol and change into
the right address or the right type.
K: W-7020 The quotation mark is not a pair. Confirm the quotation mark (the double quotation mark or the
single quotation mark).
K: W-7021 Address is undefined. Add the address.
K:W-7201 The undefined symbol is used.
12.2.11 Input/Output
Error code Message Cause/action
L:E-6000 I/O Error. Recheck the setting of MONIT on the PMC.
L:E-6001 The system failed in making the thread
L:E-6002 PMC parameter file read error
L:E-6003 PMC parameter file write error
L:E-6004
PMC parameter file write error
Insufficient disk space
L:E-6005
This file format is not PMC parameter
file format
L:E-6006
Can not load PMC parameter from PMC
side(Not EDIT mode)
L:E-6007
Can not store PMC parameter to PMC
side(Not emergency stop nor PWE = 1)
12.2.12 Online
Error code Message Cause/action
N:E-3001 Flash ROM Write error
The F-ROM is abnormal. Replace the F-ROM.
Contact your FANUC service center.
N:E-3002 Flash ROM Read error
N:E-3003 Flash ROM Erase error
The F-ROM is abnormal. Replace the F-ROM.
Contact your FANUC service center.
N:E-3004 Flash ROM Area error
N:E-3005 Flash ROM Program nothing
N:E-3006 Flash ROM Size error
A sequence program is larger than the F-ROM. Increase the size
of the F-ROM.
Try the CONDENCE function, which is an offline function.
N:E-3007 Flash ROM Not EMG stop
The CNC is not placed in the emergency stop state. Place the
CNC in the emergency stop state.
N:E-3008 Flash ROM Program data error
A sequence program on the PMC is destroyed. Reenter the
sequence program.
N:E-3009 Flash ROM Access request error
N:E-3011 User C program error occurs on PMC.
N:E-3012 Flash ROM Another used
N:E-3013 Flash ROM Command error
N:E-3014 Flash ROM No space
N:E-3015 Flash ROM File error
N:E-3016 Flash ROM File not match
N:E-3017 Flash ROM Un-known F-ROM
N:E-3018 Flash ROM I/O error
N:E-3019 Flash ROM Undefine error code
