Open CNC (Ladder Editing Package, Windows) Operators manual Page 200

Operators manual

Page of 571

/ 571

4.PRINTING SEQUENCE PROGRAMS B-63484EN/05

- 172 -

2 Set the following print options on the Title tab.

Page No.

Specify a start page number for title printing (the Initially

value is 1).

Title

Specify a title to be printed (the Initially value is "Title

Data").

Sub Title

Specify a subtitle to be printed (the Initially value is blank).

3 To preview title printing, click the <Preview> button.

4 To set up the print options, click the <OK> button.

To cancel the setup of the print options, click the <Cancel>

button.

The [Print] screen appears again.

5 To print, click the <OK> button.

To quit without printing, click the <Cancel> button.
