9.DIAGNOSIS B-63484EN/05

- 324 -

Trigger Mode

This item can be set when the tracing stop condition is

[TRIGGER]. Set the trigger mode for stopping tracing.

RISING EDGE : Automatically stops at the rising edge of the

trigger signal.

FALLING EDGE : Automatically stops at the falling edge of the

trigger signal.

BOTH EDGE : Automatically stops when the trigger signal

status changes.

Sampling Condition

This item can be set when the sampling mode is [Signal

Transition]. Set the sampling condition.

TRIGGER : Samples data when the sampling trigger

condition is satisfied.

BOTH EDGE : Samples data when the sampling address signal

changes.

Sampling Trigger Address

This item can be set when the sampling mode is [Signal

Transition] and the sampling condition is [TRIGGER]. Set the

address at which sampling is to be triggered.

Sampling Trigger Mode

This item can be set when the sampling mode is [Signal

Transition] and the sampling condition is [TRIGGER]. Set the

trigger condition mode.

RISING EDGE : Samples data at the rising edge of the trigger

signal.

FALLING EDGE : Samples data at the falling edge of the

trigger signal.

BOTH EDGE : Samples data when the trigger signal status

changes.

ON : Samples data when the trigger signal is on.

OFF : Samples data when the trigger signal is off.

Initialization button

Initializes the trace parameters in the PMC.

New Parameter button

Obtains the current PMC trace parameters.

Details button

Displays the [Trace Mode Details Parameter] dialog box.

Stores the settings and closes the dialog box.

Cancel

Closes the dialog box without storing the settings.
