B-63484EN/05 6.MNEMONIC EDITING

- 231 -

6.4 MNEMONIC FILE SAMPLE

This section provides examples of mnemonic files for the single

format and All format.

6.4.1 Single Format

This section shows a sample file for each single-format data.

6.4.1.1 Parameter

%@0

2 BCD → Counter data type

3 NO → Presence or absence of operator panel

4 PMC-RC4 → PMC type

5 000000 → Head address of language program link control statement data

6 50 → Time ratio to execute language program

7 100 → Ladder execution time

Counter data type

BINARY or BCD

Presence or absence of operator panel

No operator panel: NO

Operator panel: YES X0000

Y0000 R0000 R0010

KEY address KEY image address

LED address LED image address

PMC type

Table 6.4.1.1

PMC model Setting data (half-size string)

30i-A PMC

30i-A PMC(2nd)

30i-A PMC(3rd)

30i-A PMC(DCS)

30i-A PMC(EXT)

30i-A PMC(2nd,EXT)

30i-A PMC(3rd,EXT)

30i-A PMC(DCS,EXT)

31i-A PMC

31i-A PMC(2nd)

31i-A PMC(3rd)

31i-A PMC(DCS)

31i-A PMC(EXT)

31i-A PMC(2nd,EXT)

31i-A PMC(3rd,EXT)

31i-A PMC(DCS,EXT)
