12.ERROR MESSAGES B-63484EN/05

- 392 -

Error code Message Cause/action

E:E-6056 END FUNCTION MISSING

Function instructions END1, END2, END3, and END are

incorrect. Check that the order of END1, END2, END3, and END

is correct.

E:E-6057 PROGRAM NOTHING

E:E-6058 LADDER BROKEN

A ladder is destroyed, so that it cannot be updated. Reenter the

ladder.

E:E-6059 COIL NOTHING

E:E-6060 CALL CALLU FUNCTION MISSING

Function instructions CALL and CALLU are incorrect.

Create function instructions CALL and CALLU on the second

level of a ladder or in a sub-program.

E:E-6061 COM FUNCTION MISSING (CALL SP)

Function instruction CALL or CALLU is found between function

instructions COM (SUB9) and COME.

CALL and CALLU cannot be created between COM and COME.

E:E-6062 JMP FUNCTION MISSING (SP)

The method of using function instruction JMP (SUB10) in a

sub-program is incorrect. Check that JMP is correctly paired with

JMPE (SUB30).

E:E-6063 SUB PROGRAM MISSING

The method of using function instruction SP is incorrect. Check

that SP is paired with SPEED correctly.

E:E-6064 SP NO. DUPLICATE

The same sub-program number already exists.

Change the sub-program number.

E:E-6065 SUB PROGRAM NOTHING Create a sub-program.

E:E-6066 END FUNCTION NOTHING Add the END instruction.

E:E-6067 SP FUNCTION MISSING

E:E-6068 LBL COUNT OVER Reduce the number of labels.

E:E-6069 LBL NO. DUPLICATE

The same label number already exists.

Change the label number.

E:E-6070 LBL FUNCTION NOTHING (JMPB)

Function instruction LBL specified by JMPB is not found. Add the

LBL function instruction.

E:E-6071 COM FUNCTION MISSING (JMPB)

Function instruction JMPB is found between function instructions

COM and COME. No jump can be made beyond COM and

COME. Ensure that JMPB is not inserted between COM and

COME. Alternatively, also create specified function instruction

LBL between COM and COME.

E:E-6072 JMPB FUNCTION MISSING

The JMPB instruction allows a jump to be made to a

sub-program only. Ensure that a jump is made to a point within a

sub-program.

E:E-6073 LBL FUNCTION NOTHING (JMPC)

Function instruction LBL, specified by JMPC, is not found. Add

function instruction LBL.

E:E-6074 COM FUNCTION MISSING (LBL)

Specified function instruction LBL is found between function

instructions COM and COME. A jump cannot be made to a point

between COM and COME. Ensure that LBL is not inserted

between COM and COME. Alternatively, also create function

instruction JMPC between COM and COME.

E:E-6075 JMPC FUNCTION MISSING

Function instruction JMPC is not specified in a sub-program.

Create function instruction JMPC in a sub-program.

E:E-6076 LBL FUNCTION MISSING (JMPC)

Function instruction LBL, specified by function instruction JMPC,

is not specified at the second level of a ladder. Create function

instruction LBL at the second level of a ladder.

E:E-6077 An illegal program number is specified for

the **** instruction.

Use a P address as the parameter of functional instruction ****.

E:E-6078 An illegal label number is specified for the

**** instruction.

Use a L address as the parameter of functional instruction ****.

E:E-6080 LADDER ILLEGAL A ladder is incorrect. Reenter the ladder.
