Open CNC (Ladder Editing Package, Windows) Operators manual Page 339

Operators manual

Page of 571

/ 571

B-63484EN/05 9.DIAGNOSIS

- 311 -

Mask Bit

Specify the bits of the signals that need not be traced.

(The buttons of the signals to be traced are in the down state.)

The parameter settings become valid when the execution of signal

tracing is selected.

NOTE

1 While the signal analysis function is being used,

the signal trace function cannot be used.

2 During online monitoring, the PMC signal trace

screen cannot be displayed.

CAUTION

When the address type is physical address,

starting tracing with an illegal memory address

specified may result in a system error. To specify a

valid physical address, the user needs to be

familiar with PMC programming in C language.

Refer to the " C language Programming Manual"

(B-61863E-1), and specify a valid memory address.

9.6.7 Automatic Trace Function at Power-On

If trace parameters are set, and [Signal Trace Start] is selected on the

[Set Up] screen for PMC parameters, tracing will start automatically

when the power to the CNC is turned on.
