B-63484EN/05 12.ERROR MESSAGES

- 401 -

Error code Message Cause/action

J:W-4301

This Memory card format file is not for

expanded R/D address.

If the PMC version of PMC-RC is less than 3, R/D extended

addresses are not supported. Change the PMC version by

system parameter editing.

J:W-4800 **** Memory card format file illegal.

The header section of the memory card format file **** is invalid,

but execution is continued.

J:W-4900 'OPTION' read failed.

The default setting was used.

Settings in the option file of a selected program cannot be read.

Prepare a file, or correct the settings. Execution is made possible

by option resetting.

J:W-4901 '%%%FLSET.CNF' read failed.

Symbol characters are not checked.

Settings in the %%%FLSET.CNF file cannot be read. Prepare a

file, or correct the settings. Execution is possible if symbol

characters are not checked.

J: W-7200 Prog. is out of range.(Prog.)

J: W-7201 The symbol does not exist.(Address)

J: W-7202

The symbol has exceeded the limitation

length of characters.(Prog., Symbol)

J: W-7203

The symbol used the limitation

character.(Prog., Symbol)

J: W-7204

The paragraph of comment exceeded the

number of limitations.(Prog.:$, Symbol:$)

J: W-7205

The comment has exceeded the limitation

length of characters.(Comment)

J: W-7206

The comment used the limitation

character.(Comment)

J: W-7210 Address and type does not exist.

J: W-7211

This symbol cannot be defined as the

local symbol.(Prog., Symbol, Address)

J: W-7212

The symbol of the same name as the

already inputted global symbol cannot be

inputted.(Prog., Symbol)"

J: W-7213

The symbol of the same name as the

already inputted local symbol cannot be

inputted.(Prog., symbol)

J: W-7214 Prog. is illegal.(Prog.)

J: W-7215 Attribute is illegal.(Attribute)

J: W-7216

Address and Attribute are

contradictory.(Address, Attribute)

J: W-7217

Address and Type are

contradictory.(Address, Type)

J: W-7218 Type does not exist.

J: W-7219 Type is illegal.(Type)

12.2.10 Mnemonic Conversion

Error code Message Cause/action

K:F-2000 Insufficient memory.

K:F-2001 Insufficient disk space.

K:F-2006 Not found **** file.

K:F-2100 Not found * file.

K:F-2101 Set-up file broken.

K:F-2102 Illegal option(s).
