B-63484EN/05 9.DIAGNOSIS

- 297 -

<6> Display format: Double word

<8> Display type: Bit

<8> Display type: Decimal

<9> Display type: Hexadecimal

<10>Display type: BCD

<11>Sign indication (off ↔ on)

<12>Write protection

9.3.5.2 Status bar

Fig. 9.3.5.2

<1> Group name

<2> Range of data area

<3> Number of data items

<4> Display format

[Byte], [Word], or [Dword] is indicated.

<5> Display type

[Bit], [Decimal], [Hex], or [BCD] is indicated.

9.3.5.3 Shortcut keys

Table 9.3.5.3

Shortcut keys Corresponding function

[F4] Symbol indication (off↔on)

[Ctrl]+[F] Search

9.3.5.4 Input data range

Table 9.3.5.4

Byte Word Double word

Decimal -128 to 127 -32,768 to 32,767 -2,147,483,648 to 2,147,483,647

Hexadecimal 0 to FF 0 to FFFF 0 to FFFFFFFF

BCD 0 to 99 0 to 9,999 0 to 99,999,999

9.3.5.5 Context menu

Fig. 9.3.5.5

<5><3><2><1> <4>
