11.CONVERTING SEQUENCE PROGRAMS B-63484EN/05

- 382 -

Example of conversion (PMC-SB3 → PMC-SC3)

1 To convert a source program to mnemonic file format, set the

PMC model to PMC-SB3.

2 Using a text editor, change the setting of system parameters so

that they match the PMC-SC3.

3 For FANUC LADDER-II, set the PMC model to PMC-SC3 to

convert the mnemonic file manipulated in step 2 to a source

program.

%@A

%@0

2 BCD

3 NO

4 PMC-RB3

7 100

%@1

01 ABC-KIKAI

02 S-DRILL

%@5

X000 1 0 1 ID16C

Y008 1 0 4 OD32A

%@E

%@A

%@0

2 BCD

3 NO

4 PMC-RC3

5 000000

6 50

7 100

%@1

01 ABC-KIKAI

02 S-DRILL

%@5

X000 1 0 1 ID16C

Y008 1 0 4 OD32A

%@E

Changing

system

parameters

Mnemonic file

to be converted

(PMC-SB3)

Mnemonic file to be

created by conversion

(PMC-SC3)

NOTE

For an explanation of the setting items of the

system parameter section of each model, see

Subsection 6.4.1.1, "Parameter" in Section 6.4,

"MNEMONIC FILE SAMPLE".
