B-63484EN/05 10.EXTENDED SYMBOL/COMMENT FUNCTION

- 333 -

Case Conditions Example Result

e.5 Global symbol is different and address is the

same.

ABC

ABCD

; Global symbol

(O)

e.6 Global symbol is different to local symbol and

address is the same.

ABC

ABCD

; Global symbol

; Local symbol(P1)

(O)

e.7 Local symbol is different to other local symbol

and address is the same.

ABC

ABCD

; Local symbol(P1)

; Local symbol(P2)

(O)

e.8 Symbol is different within local symbol and

address is the same.

ABC

ABCD

; Local symbol(P1)

(O)

(f) The symbol for P address.

P address can only be used as global and cannot be used as local

address. The scope of symbols for P address is checked

differently with other symbols as below.

Fig. 10.1.1 (h)

Case Conditions Example Result

f.1 Global symbol is the same ABC

ABC

; Global symbol

(X)

f.2 Global symbol is different and address is the

same.

ABC

ABCD

; Global symbol

(O)

f.3 Global symbol is different and address is

different.

ABC

ABCD

; Global symbol

(O)

NOTE

1 When you decompile the ladder object code

containing the references to the symbols with the

same address, such references may not get back to

the symbol in the original source program. The

symbol name may be changed to one of the symbols

selected by decompiler.

2 When multiple symbols are defined for the same

address, only one symbol selected by the system is

displayed in the address display of the signal status

screen etc. on PMC. Other symbols are not displayed.

10.1.2 About the Symbol Type

Type can be set to the symbol.

BOOL: Set to the symbol which is used as basic instructions.

BYTE, WORD, DWORD: Set to the symbol which is used as

parameters for function instructions.

10.1.3 About the Distinction of Symbol and Address

In case that a symbol R10 is defined, "R10" is interpreted as R10 of

symbol. If you want to enter address R10 explicitly, "%R10" is to be

input. "% + address" should be used when you want to input it

specifically in the address. Without the definition of the symbol R10,

you do not need to input with %. In case of the mnemonic file of

extended function, it is always necessary to add % to the address
