<2> Trace start button
Starts or stops tracing.
When this button is in the up state, tracing is stopped.
When the button is in the down state, tracing is executed.
* When the trace function is being executed, the <Trace start>
button is in the down state.
<3> Symbol on/off button
Sets the display format of the trigger and sampling addresses.
When the symbol format is selected, the button is in the down
state; when the address format is selected, the button is in the up
state.
<4> Marking button
Marks the cursor position at that time and displays the mark
cursor. When the mark cursor and current position cursor overlap
one another, the current position cursor is displayed. At the
bottom of the screen, [Mark position], the mark cursor position,
and [Range], the range from the mark cursor position to the
current position cursor, are displayed.
<5><6> Zoom button
Magnifies or reduces graphs.
<7> Grid line button
Specifies whether to display grid lines.
<8><9> Up-and-down replacement button
Clicking the [UP] button replaces the trace result at the address
cursor with the line immediately above.
Similarly, clicking the [DOWN] button replaces the trace result
with the line immediately below.
The display after replacement is held until the next execution of
tracing.
<10>Search button
Searches the trace display area for the specified time or frame
number.
<11>First trace result button
Moves the cursor at the beginning of the trace result.
<12>Previous trace result button
Scrolls the trace result display up by one page.
<13>Next trace result button
Scrolls the trace result display down by one page.
<14>Last trace result button
Moves the cursor at the end of the trace result.
9.10.3 Status Bar
<1> <2> <3> <4> <5>
Fig. 9.10.3
<1> Sampling mode
The current selected sampling mode is indicated.
<2> Resolution
The current resolution setting is indicated.
