Example of outputting zero suppression

(1) For the zero suppression is invalid

%@2-E(SYM=1 SCP=2 TYP=3 ADR=4 CM1=5 CM2=6 CM3=7 CM4=8)

*ESP,,BOOL,G0008.4,Emergency stop,,,

MCODE,,BYTE,F0010,Supplementary function code (BIN),,,

,,BOOL,X0000.0,Operation power supply insertion,,,

,,BOOL,X0008.4,*ESP(Operation preparation completion),,,

Fig. E.4(b)

(2) For the zero suppression is applied

%@2-E(SYM=1 SCP=2 TYP=3 ADR=4 CM1=5 CM2=6 CM3=7 CM4=8)

*ESP,,BOOL,G8.4,Emergency stop,,,

MCODE,,BYTE,F10,Supplementary function code (BIN),,,

,,BOOL,X0.0,Operation power supply insertion,,,

,,BOOL,X8.4,*ESP(Operation preparation completion),,,

Fig. E.4(c)
