Open CNC (Ladder Editing Package, Windows) Operators manual Page 7

Operators manual

Page of 571

/ 571

B-63484EN/05 PREFACE

p-1

PREFACE

Thank you for purchasing Ladder Editing Package (Windows)

(Specification : A08B-9210-J511).

Ladder Editing Package (Windows) is a programming system for

developing sequence programs for FANUC PMCs.

This software runs on a FANUC OPEN CNC.

Use the sequence program development software listed below to

develop sequence programs, using a personal computer that operates

independently of a FANUC OPEN CNC. For how to use the software,

refer to the respective operator's manuals.

Name Operator’s Manual

FANUC LADDER FANUC LADDER Operator’s Manual (B-66131E)

FANUC LADDER-II FANUC LADDER-II Operator’s Manual (B-66184EN)

FANUC LADDER-III FANUC LADDER-III Operator’s Manual (B-66234EN)

This software runs under the Microsoft

Windows

environment. This

manual does not cover common basic Windows operations. If you are

a beginner to Windows, read the Windows manual first to learn the

basic Windows operations.

This manual describes the programming system-specific items

including the methods of installing, starting, and using this software.

For details on how to create sequence programs for FANUC PMCs

and how to operate PMCs, refer to the following manuals:

• FANUC PMC MODEL PA1/PA3/SA1/SA2/SA3/SA5/SB/SB2/

SB3/SB4/SB5/SB6/SB7/SC/SC3/SC4/NB/NB2/NB6

Ladder Language Programming Manual (B-61863E)

• FANUC Series 30i/300i/300is-MODEL A

FANUC Series 31i/310i/310is-MODEL A5

FANUC Series 31i/310i/310is-MODEL A

FANUC Series 32i/320i/320is-MODEL A

PMC Programming Manual (B-63983EN)

Read this manual thoroughly to ensure the correct use of Ladder

Editing Package (Windows).

NOTE

After purchasing this software, you can copy it for

use at your factory as needed. Attach a copy to a

machine to be shipped as a backup.

FANUC owns the copyright of the software. No one

is allowed to redistribute it, in part or in whole, to

any third party with an aim to use it for application

development.

Microsoft and Windows are registered trademarks of Microsoft

Corporation in the United States of America.
