Open CNC (Ladder Editing Package, Windows) Operators manual Page 355

Operators manual
B-63484EN/05 9.DIAGNOSIS
- 327 -
Edit Box of Address Setting
Enter the address or symbol of a signal to be sampled in the edit
box and click the <Append Address> button. The address or
symbol is added to the list box. Set a signal address with a bit
address. If a byte address is entered, the address indicated by bits
0 to 7 of the entered address is input. Up to 32 signal addresses
can be set.
Sampling Address List
When the trace sampling mode is [Signal Transition] and the
sampling condition is [ANY CHANGE], you can specify
whether to use each set address as a sampling trigger signal.
Check the check box corresponding to a desired signal to use the
signal as a sampling trigger signal.
Append Address button
Adds the new sampling address entered in the edit box.
Change Address button
Replaces the set address or symbol at the cursor with the contents
of the edit box.
Delete Address button
Deletes the set address or symbol at the cursor from the list box.
All Delete button
Deletes all sampling addresses set in the list box.
↑ button
Replaces the set address at the cursor with the address on the line
immediately above.
↓ button
Replaces the set address at the cursor with the address on the line
immediately below.
OK
Stores the settings and closes the dialog box.
Cancel
Closes the dialog box without storing the settings.
