Open CNC (Ladder Editing Package, Windows) Operators manual Page 568

Operators manual

Page of 571

/ 571

Replace the Table 5.1(a) of "5.1 COMPILATION"

Table 5.1(a)

Option Explanation

Condense

When a ladder that has the same number of steps is

compiled, the object code is decreased.

Output Symbol/Coil-comment

A symbol that can be displayed on a display unit of

CNC, and an accompanying coil comment are output

to an object code.

Ignore too long strings of the

symbol

Any symbol that exceeds six characters in length is

replaced by a space code of six characters and

output to an object code together with a coil

comment.

Output Comment A coil comment is output to an object code.

Output Netcomment pointers A net comment pointer is output to an object code.

Multiple used check of the

Function parameter number

Functions TMR, TMRB, TMRBF, CTR, DIFU, and

DIFD are checked if they are duplicated. If any, a

warning is displayed.

Setting of Password

A password is added to an object code. Enter a

password at the start of execution.

Output warning in detail

Warning with detailed information is displayed.

Warning number: I:W-4500, I:W-4501

Coil-comment language

Specify the format in which to output a coil comment

to an object file when compiling a source program.

English:

Japanese coil comments are replaced by spaces

and output to an object file. (Conventional

specification)

Japanese:

Japanese coil comments are converted directly

and output to an object file.

FANUC OPEN CNC LADDER EDITING

PACKAGE (Windows) SUPPLEMENTARY

OPERATOR'S MANUAL

01 05/09/26 First issue B-63484EN/05-4

EDIT

DATE

DESIG.

DESCRIPTION

8/11

TITLE

DRAW.NO.

SHEET

CUST.
