12.ERROR MESSAGES B-63484EN/05

- 398 -

Error code Message Cause/action

I:E-3654

The label of **** exists in the range of the

COM instruction.

The jump destination label **** of the JMPC instruction is

specified within a COM instruction control range. Specify the label

**** outside the control range.

I: E-6270 CS instruction can not be used excluding

the 2nd level main program.

Use functional instruction CS in the LEVEL2 or the subprogram.

I: E-6271 CM instruction can not be used excluding

the 2nd level main program.

Use functional instruction CM in the LEVEL2 or the subprogram.

I: E-6272 CE instruction can not be used excluding

the 2nd level main program.

Use functional instruction CE in the LEVEL2 or the subprogram.

I: E-6330 CS instruction can not be used in the

range controlled COM instruction.

Do not use functional instruction CS between COM and COME.

I: E-6331 CM instruction can not be used in the

range controlled COM instruction.

Do not use functional instruction CM between COM and COME.

I: E-6332 CE instruction can not be used in the

range controlled COM instruction.

Do not use functional instruction CE between COM and COME.

I: E-6360 There is no CE instruction. Although the functional instruction CS is used, there is no

functional instruction CE that means the end.

I: E-6361 Another CS instruction can not be used in

the range of CS instruction.

Use CS and CE in a pair. And don’t nest a pair of CS and CE.

I: E-6362 CM instruction must be used between CS

and CE instruction.

Use functional instruction CM between CS and CE

I: E-6363 CE instruction must be used in CS

instruction and a pair.

Use CS and CE in a pair. And don’t nest a pair of CS and CE.

I: E-6365 Use only CM instruction between CS and

CE instruction.

Do not use other instructions except the functional instruction CM

between CS and CE.

I: E-6751 File I/O error.

I: E-6752 The range of the assignment is illegal.

I: E-6753 The range of assignment overlaps.

I: E-6754 The allocation range is not enough.

I:W-4100

The title data which could not be display

on the CNC was replaced with space

code.

Title data includes characters such as kana characters. Those

characters are replaced with blank characters.

I:W-4101

Illegal OP.PANEL( PARAMETER ).

Proceed to compile using 'NO'

A system parameter is set to use the FS0 operator's panel, but

addresses (such as a key input address and LED output address)

are not set.

Compilation is performed, assuming that the FS0 operator's

panel is not used.

I:W-4102 Editing sub-program has not completed. A sub-program is being edited. Complete the editing.

I:W-4103

Multiple sub-programs with same number

exist.

A sub-program with the same number exists (for example,

P1.#LA and P1.#SS). The ladder program is compiled first

(P1.#.LA, for example).

I:W-4104

The source-program is FORMAT-B. This

parameter is ignored:

SYMBOL/COMMENT

FORMAT-B outputs symbols/comments at all times.

I:W-4105

The source-program is FORMAT-B. This

parameter is ignored: NET COMMENT

FORMAT-B data does not include a net comment. Setting this

item has no effect.

I:W-4200 There is no LADDER program.

A ladder program is empty. The ladder program is not output to a

memory card format file.

I:W-4201

LADDER execution time at the 1st level is

too large.

Reduce the first level, or increase the value of the system

parameter by specifying a ladder execution time ratio.
