Open CNC (Ladder Editing Package, Windows) Operators manual Page 213

Operators manual
B-63484EN/05 4.PRINTING SEQUENCE PROGRAMS
- 185 -
2 Set up the following print options on the System Parameter tab.
Page No.
Specify a start page number for system parameter printing
(the Initially value is 1).
Title
Specify a title for system parameter printing (the Initially
value is "System Parameter").
Sub Title
Specify a subtitle for system parameter printing (the
Initially value is blank).
3 To preview system parameter printing, click the <Preview>
button.
4 To set up the print options, click the <OK> button.
To cancel the setup of the print options, click the <Cancel>
button.
The [Print] screen appears again.
5 To print, click the <OK> button.
To quit without printing, click the <Cancel> button.
