10.EXTENDED SYMBOL/COMMENT FUNCTION B-63484EN/05
- 374 -
(Example) In case of the Extended functions of 30i-A PMC (the
1st-path PMC).
%@0
2 BINARY 2 : Counter data type (BINARY or BCD)
3 NO 3 : Yes or no of Operator panel ( Valid : YES, Invalid : NO )
4 30i-A PMC 4 : PMC Type
( 30
i-A PMC )
31 1 31 : The setting number of display language(Comment) ( 1-16 )
32 -1 32 : CNC display language number 1 ( -1, 0-127 )
33 0 33 : Comment set number 1 ( 0-16 )
100 YES 100 : Yes or no of automatic assignment ( Valid : YES, Invalid : NO )
101 R100-R199 101 : BOOL of R address (Character string R100-R199)
102 R700-R799 102 : BYTE of R address
103 0-0 103 : WORD of R address
104 0-0 104 : DWORD of R address
111 D100-D149 111 : BOOL of D address (Character string D100-D149)
112 D200-D299 112 : BYTE of D address
113 0-0 113 : WORD of D address
114 0-0 114 : DWORD of D address
121 E0-E199 121 : BOOL of E address (Character string E0-E199)
122 0-0 122 : BYTE of E address
123 0-0 123 : WORD of E address
124 0-0 124 : DWORD of E address
%
10.18.2 Symbol Comment
%@2-D
Symbol Address:Type
$1 'Comment 1'
$2 'Comment 2'
$LEVEL1
Symbol Address:Type
$2 'Comment 2'
%
Fig. 10.18.2 (a)
• Describe an address and a symbol in the same line. A symbol has
to be described at the head of a line, puts a space or a tab as a
delimiter character, and describes an address.
• Describe the type of a symbol after ":" of an address. If the type
of a symbol is omitted, it will change to BOOL or BYTE
according to the kind of address.
• Input the space and address to set up only a comment.
• "$LEVEL1" and "$P1" or subsequent ones are local symbols.
• "$1" is the 1st comment and "$2" is the 2nd comment. The
character string surrounded with the single quotation mark is a
comment.
