Open CNC (Ladder Editing Package, Windows) Operators manual Page 433

Operators manual
B-63484EN/05 12.ERROR MESSAGES
- 405 -
Error code Message Cause/action
K:E-3181 Too long strings.
The length of a system parameter, message data, or title data
exceeded the maximum allowable value.
K:E-3187 Too mamy characters in 1 line.
The number of characters on one line of mnemonic data, a
mnemonic, or I/O module data in a system parameter, message
data, title data, or symbol/comment exceeded the maximum
allowable value.
K:E-3188 Too many parameters. Too many parameters are set for a function instruction.
K:E-3189 Total value of base and slot is over.
The total of the base and slot values of the I/O module data
exceeded the default.
K:E-3190 Undefined instruction. Data includes an undefined instruction.
K:E-3191 Unexpected address. An address was specified where no address is required.
K:E-3192 Unexpected parameter(s).
Parameters were specified in a function instruction that requires
no parameters.
K:E-3193 Unknown data number.
A nonexistent data number was specified as a system
parameter/data identifier.
K:E-3194 Data entry error. Symbol/comment data could not be registered.
K:E-3195
Include KANA or KANJI character(s) in
symbol data.
Full-size characters cannot be used for symbol data.
K:E-3196 Include KANA or KANJI character(s).
K: E-3197 Column number overlaps in option
setting.
Confirm the contents of the option setting of "%@3-E".
K: E-3198 The range of the assignment is illegal. Confirm the range of automatic address assignment.
K: E-3199 The range of assignment overlaps. Confirm whether the range of automatic address assignment
overlaps others.
K: E-3200 The allocation range is not enough. Increase the range of automatic address assignment.
K: E-3201 The label number exceeded the limit. The label is not assigned because limitation of the number of
labels was exceeded.
K: E-3202 Automatic assignment of the address
was unsuccessful.
Compile the ladder and perform automatic address assignment.
K:E-6001 Cannot be handle data type '%@2-D'.
K:E-6101 The address of symbol is undefined.
K:E-6201
The limitation character is used for the
symbol.
K:E-6202
This functional instruction cannot use
the local symbol.
K:E-6301 The address of symbol is undefined.
K:W-4100 Comment data not found. Data consisting of symbols only was converted to an address.
K:W-4101 Data not found.
System parameters, message data, title data,
symbols/comments, and I/O module data are not found.
K:W-4102 Deleted KANJI characters.
K:W-4103 Expected control condition(s). No control condition is set for a function instruction.
K:W-4104 Illegal characters are specified at ****. Invalid data was specified in ****.
K:W-4105
Illegal OP.PANEL( PARAMETER ).
Proceed to convert with using 'NO'.
The system parameter OP.PANEL (parameter) is invalid.
Conversion is performed assuming "NO."
K:W-4106 Illegal symbol.
The symbol data does not satisfy the standard (check level-1).
(FORMAT-C)
K:W-4108
Include KANA or KANJI character(s) in
comment data.
Comment data including full-size characters was converted
without selecting the full-size character conversion option (J
option).
K:W-4109
Logical operated with unused
register(s).
An operation was performed with a register not entered in the
ladder data.
K:W-4110 Logical product remains in register(s). A register was not output to ladder data.
