Open CNC (Ladder Editing Package, Windows) Operators manual Page 166

Operators manual
3.CREATING AND EDITING SEQUENCE PROGRAMS B-63484EN/05
- 138 -
NOTE
1 Sum of integer part digits and fractional part digits
must be within 8.
2 Do not use any space between the brackets, [ ].
3 With the view function, as many number signs (#) as
the number of specified digits are displayed in bold.
(Example: ###.##).
(b) Input method of Numeric data
Numeric data
Input mode MSG_EDIT_VAL
Input Display
1
[Ibid,{{{{] [Ibid,{{{{]Japanese-language
input mode
0
NA •••••••••••
1
[Ibid,{{{{] [Ibid,{{{{]
Code input mode
0
[Ibid,{{{{] [Ibid,{{{{]
(c) Input method of character ‘[’, ‘]’ and ‘@’
In the numeric data input, Character ‘[‘ and ‘]’ are used as a
delimitation character. The input method of character ‘[’, ‘]’
and ‘@’ in the each input mode is as follows.
‘[’ ‘]’ ‘@’
Input mode MSG_EDIT_VAL
Input Display Input Display Input Display
1
@5B@ @5B@ @5D@ @5D@ @40@ @40@Japanese-language
input mode
0
[ [ ] ] @ @
1
@5B@ @5B@ @5D@ @5D@ @40@ @40@
Code input mode
0
@5B@ @5B@ @5D@ @5D@ @40@ @40@
