Series 15i/150i - MA (Operation) Operators manual Page 138

Operators manual

Page of 628

/ 628

B-63324EN-1/03 OPERATION 4.AUTOMATIC OPERATION

- 117 -

- Restart

When a program is edited while MDI operation is stopped, then the

program is restarted, the program execution starts from the cursor

position.

MDI operation program (for the FS16 type)

- Program erasure

A program created in MDI mode is erased when:

- M02, M30, or ER (%) is executed as part of MDI operation.

- If bit 6 (MZE) of parameter No. 2458 is set to 1, the last block in

the program has been executed in single block operation.

- Memory operation is performed.

- DNC operation is performed.

- Editing is performed in EDIT mode.

- If bit 7 (MCL) of parameter No. 2458 is set to 1, reset key

RESET

pressed.

- Address key

is input, then edit key

DELETE

is pressed.

NOTE

If bit 7 (MCL) of parameter No. 2458 is set to 0, a reset

operation performed during MDI operation does not

erase the program in MDI operation but clears the

modal information. When the following parameters

are set to 1, however, part of the modal information

can be maintained:

- Bit 7 (NCM) of parameter No. 2401: G00 to G03,

G17 to G19, and so forth

- Bit 5 (K43) of parameter No. 2409: G43 to G49 and

H code

- Bit 6 (KWZ) of parameter No. 2409: G54 to G59

- Program editing during operation

Program editing can be performed during MDI operation. If bit 5

(MZE) of parameter No. 2458 is set to 1, editing can be disabled until a

reset.

- Program registration

Programs created in MDI cannot be registered.

- Subprogram nesting

A subprogram call command (M98) can be specified in a program

created in MDI. This means that a program registered in memory can

be called and executed by MDI operation. Up to ten nesting levels are

allowed in a subprogram call.

- Macro call

If the custom macro option is provided, a macro program can be called

and executed in MDI mode.
