10.DISPLAY OPERATION B-63324EN-1/03

- 520 -

Function details

Storing disturbance load torque data

While the torque sensing command signal is 1, the CNC holds the

disturbance load torque data detected by a servo motor or spindle motor

in internal memory. Up to four target axes can be specified in

parameter Nos. 4670 to 4673. Specifying a servo motor as a target axis

requires that bit 0 of servo parameter No. 1958 be set to 1.

If the sample data preservation function is enabled (parameter SPL (bit

2 of parameter No. 4660) = 1), the stored torque data can be saved as

sample data. The original torque data is called the "latest data" in

contrast with the sample data. The time during which the data can be

stored varies according to the number of storage target axes and the

storing interval, as listed below.

Storing interval

Number of target axes

8ms 16ms 32ms

1 About 69.9

minutes

About 139.8

minutes

About 279.6

minutes

2 About 34.9

minutes

About 69.9

minutes

About 139.8

minutes

3 or 4 About 17.4

minutes

About 34.9

minutes

About 69.9

minutes

NOTE

1 The disturbance load torque data is represented as a

percentage of the rated torque.

2 If the sample data preservation function is enabled

(parameter SPL (bit 2 of parameter number 4660) =

1), the time during which the torque data can be

stored becomes half.

3 If the value in the above table is exceeded, no more

data will be stored, even if the torque sensing

command signal is 1.

4 The stored torque data is erased when the power is

switched off. If you want to keep the torque data after

the power is switched off, save it as sample data or

save it to a memory card.

5 When the torque sensing command signal is reset to

0, the CNC suspends storing the torque data. When

the signal is set to 1 again, the CNC restarts to store

the torque data from a point of break. To start storing

from scratch, input the store counter clear signal.

6 Even when an attempt is made to store the servo

motor torque data and the spindle motor torque data

at the same time, they are not for the same time. This

is because the servo motor data may delay by up to 9

ms.
