10.DISPLAY OPERATION B-63324EN-1/03

- 450 -

- Graphic axis numbers

Specify which controlled axes are to be assigned to the graphic axes.

First graphic axis : 1

Second graphic axis : 2

Third graphic axis : 3

Axis not subject to drawing : 0

NOTE

1 When the maximum and minimum of the graphic

range are set, the graphic center and the scale factor

are automatically updated. On the other hand,

changing the graphic center and the scale factor

does not cause the maximum and minimum of the

drawing range to be updated.

2 The settings of the graphic parameters take effect

when the [ERASE] soft key is pressed on the tool

path graphic screen. Graphic colors, however, take

effect as soon as they are set.
