B-63324EN-1/03 OPERATION 8.EDITING PROGRAMS

- 265 -

8.6.3 Replacing Addresses

Confirming each replacement

Procedure

Method 1

(1) Press the [ALTER] soft key.

(2) Key in the address to be replaced.

(3) Press the [(Address)] soft key.

(4) Key in a new address.

(5) Press the [EXEC SINGLE] soft key.

The system searches for the address to be replaced and the

cursor is positioned to the address.

(6) To replace the address, press the [EXEC SINGLE] soft key.

The address is replaced and the system searches for the next

occurrence of the address.

(7) To search for the next occurrence of the address without

performing replacement, press the [SKIP] soft key.

The system searches for the next occurrence without

replacing the address.

(8) To replace all the remaining occurrences of the address,

press the [EXEC] soft key.

(9) To end the replacement prior to the completion of the search,

press the [STOP] key.

(10) When replacement ends, the total number of replacements is

displayed.

Method 2

(1) Press the [ALTER] soft key.

(2) Key in the address to be replaced, followed by a new address,

as shown in the example.

Example: To replace U with X, enter U,X.

(3) The subsequent steps are the same as (5) to (10) of method 1.

Method 3

(1) Key in the address to be replaced, followed by a new address,

as shown in the example.

Example: To replace U with X, enter U,X.

(2) Press the [ALTER] soft key.

The system searches for the address to be replaced and the

cursor is positioned to the address.

(3) The subsequent steps are the same as (6) to (10) of method 1.
