Series 15i/150i - MA (Operation) Operators manual Page 520

Operators manual

Page of 628

/ 628

B-63324EN-1/03 OPERATION 10.DISPLAY

- 499 -

(2) Main screen edit state

In this state, the sub screen is displayed but the object of editing is

the main screen. The title bar of the sub screen is dark gray.

Page keys , cursor keys ,

and soft keys all act on the main screen.

(3) Main screen edit state

In this state, the sub screen is displayed and the object of editing is

the sub screen. The title bar of the sub screen is blue.

When displayed, the sub screen first enters the sub screen edit

state.

Page keys , cursor keys ,

and soft keys all act on the sub screen.

The switching of a sub screen between the main screen edit state and

the sub screen edit state is performed as shown below.

PAGE

Press ,

then numeric key .

SHIFT

Sub screen

edit

state

Main

screen

edit

state

Press soft key

[RETURN MAIN].The title bar of

the sub screen

is blue.

The title bar of

the sub screen

is dark gray.
