B-63324EN-1/03 OPERATION 8.EDITING PROGRAMS

- 249 -

NOTE

1 To encrypt programs, set parameter EIA (bit 4 of No.

0000) to 0 (to specify that the punch code is ISO).

2 An encrypted program cannot be registered as an

additional program ([READ]-[1_PROGRAM]-[ADD]).

3 Programs outside the security range cannot be input

from encrypted programs.

Program display

1 On the program directory screen, all program numbers are

displayed together with comments.

2 On the program text screen:

When the program memory is locked, programs within the

security range are not displayed.

When the program memory is unlocked, all the programs are

displayed.

The change from the unlocked state to the locked state or from the

locked state to the unlocked state is not applied to the display

immediately. The change takes effect when, for example, a

program search is performed.

Editing and deleting programs

When the program memory is locked, the programs within the security

range cannot be edited or deleted. When the program memory is locked,

an attempt to delete all programs results in only those programs outside

the security range being deleted.

Searching for programs

In the locked state, a program search is performed within the protected

range as described below.

1 When no program number is specified (by using [FRWRD

SEARCH] and [NEXT PRGRAM], for example), programs

within the protected range are skipped.

2 When a program number is specified for a program search within

the protected range (by using [FRWRD SEARCH], [PROG#],

program-number, and [EXEC], for example), and the search finds

a matching program, the program is selected. However, the

warning message "INVISIBLE PROGRAM" is displayed. On the

program text screen, the number of the matching program is

displayed as an O number. However, "PROGRAM NOT

FOUND" is displayed for the program contents.
