Series 15i/150i - MA (Operation) Operators manual Page 394

Operators manual

Page of 628

/ 628

B-63324EN-1/03 OPERATION 9.SETTING AND DISPLAYING DATA

- 373 -

- (D) Length

Length represents a tool length compensation value. When a tool

number is specified, the tool compensation value corresponding to the

tool number is used for tool length compensation.

- (E) Radius

Radius represents a cutter compensation value. When a tool number is

specified, the cutter compensation value corresponding to the tool

number is used for cutter compensation.

- (F) Relative coordinates

Relative coordinates are displayed.

- (G) Tool offset increment system

/execution/selection

The increment system of tool offset values, and the display number of

the tool data that is currently being executed/selected are displayed.

The tool data that is currently being executed is that for which

compensation is enabled (with M06 specified after the T code). The

currently selected tool data is that which is selected (with T code

selected but M06 not specified). When no tool data is currently

executed/selected, *** is displayed.

Selecting and setting tool offset data

Entering and modifying

tool offset data

Method 1

(1) Position the cursor to the data you want to enter or modify.

(2) Press the [INPUT] soft key.

(3) Enter data.

(4) Press the [EXEC] soft key.

Method 2

(1) Position the cursor to the data you want to enter or modify.

(2) Enter data.

(3) Press the [INPUT] soft key.

Method 3

(1) Position the cursor to the data you want to enter or modify.

(2) Enter data.

(3) Press the

INPUT

key.
