Series 15i/150i - MA (Operation) Operators manual Page 181

Operators manual

Page of 628

/ 628

4.AUTOMATIC OPERATION OPERATION B-63324EN-1/03

- 160 -

Limitation

1. After the retraction position is specified with G10.6 using an absolute

command, any changes in the origin, preset, and workpiece origin

offset (or external workpiece origin offset) will not be reflected in the

retraction position. If, therefore, these operations are performed or

the workpiece origin offset (or external workpiece origin offset) is

changed, the retraction position must be re-specified with G10.6.

2. When retracting the tool by manual operation in the tool retraction

mode, do not use the machine lock, mirror image, or scaling function.

Alarm

Number Message Contents

PS0183 TOO MANY SIMULTANEOUS AXES

A move command was specified for more axes than can be

controlled by simultaneous axis control.

Either add on the simultaneous axis control extension

option, or divide the number of programmed move axes

into two blocks.

PS0215 ILLEGAL COMMAND IN G10.6 The retract command was specified in the long axis for

threading when retract was started by the threading block.

WARNING

The retraction axis specified by G10.6 and the

distance the tool is retracted need to be changed in

the necessary block according to the figure to be

machined. If correct retraction is not specified, the

tool or the workpiece may be damaged.
