7.ALARMS AND SELF DIAGNOSTC FUNCTIONS OPERATION B-63324EN-1/03

- 216 -

Setting periodic maintenance data

Set periodic maintenance data on the item setting screen.

Setting an item name

- Setting by MDI key input

Position the cursor to a desired item name by using the

cursor keys .

2) Key in an item name in the input format, explained later.

Press the

[INPUT]

soft key or the key.

The item name is set, and the service life, remaining time, and

count type are initialized.

4) When an item name is keyed in, and the [+INPUT] soft key is

pressed, the item name is added to an already-set item name. In

this case, the life time, remaining time, and count type are not

initialized.

- Setting by selection from the item selection menu screen

Position the cursor to a desired item name by using the

cursor keys .

2) Press the [SELECTITEM] soft key.

The menu screen appears.

3) Select a desired name from the item names registered on the item

selection menu screen by positioning the cursor to that name.

4) Press the [SELECTEND] soft key.

The item setting screen is redisplayed, and the selected item name

is set.

INPUT
