7.ALARMS AND SELF DIAGNOSTC FUNCTIONS OPERATION B-63324EN-1/03

- 218 -

NOTE

If an item name is not set, the service life cannot be

set.

Setting the remaining time

Position the cursor to the desired remaining time by

using the cursor keys .

2) Key in a time. The set value must range from 0 to 999999 (hours).

Press the

[INPUT]

soft key or the key.

4) When a time is keyed in, and the [+INPUT] soft key is pressed, the

set value is added to the existing remaining time.

NOTE

If no item name is set, the remaining time cannot be

set.

Setting the count type

Position the cursor to a desired count type by using the

cursor keys .

2) Select a count type by pressing the [NO COUNT], [ALL TIME],

[POWER ON], [AUTO START], or [CUTTING] soft key.

Deleting an item

1) Press the [CLEAR ITEM] soft key.

2) Key in the item number (1 to 10) you want to delete.

3) Press the [EXEC] soft key.

Creating an item selection menu

Display the item selection menu screen.

Setting an item name

Position the cursor to a desired item name by using the

cursor keys. Only the machine

menu can be edited.

2) Key in an item name in the input format described previously.

Press the

[INPUT]

soft key or key.

INPUT
