B-63324EN-1/03 OPERATION 10.DISPLAY

- 469 -

- Graphic axis numbers

Specify which controlled axes are to be assigned to the graphic axes.

First graphic axis : 1

Second graphic axis : 2

Third graphic axis : 3

Axis not subject to drawing : 0

NOTE

1 When the maximum and minimum of the graphic

range are set, the graphic center and the scale factor

are automatically updated. On the other hand,

changing the graphic center and the scale factor

does not cause the maximum and minimum of the

drawing range to be updated.

2 The settings of the graphic parameters take effect

when the [ERASE] soft key is pressed on the tool

path graphic screen. Graphic colors, however, take

effect as soon as they are set.

- Graphic program number

Set the number of the program whose tool path is to be drawn.

Press the [REWIND] soft key to move the graphic program pointer to

the beginning of that program.

- Graphic start/end Nos.

To draw only a portion of the tool path of a program, set the sequence

numbers to specify the start and end blocks, in addition to the program

number. If 0 is set for both numbers, the entire tool path of the program

specified with the graphic program number is drawn.

NOTE

The blocks specified by the program number and the

sequence numbers must be independent blocks or

blocks containing NC statements. If the blocks

contain instructions for calling subprograms or macro

programs, the blocks are ignored.
