8.EDITING PROGRAMS OPERATION B-63324EN-1/03

- 268 -

8.8 CUTTING AND PASTING

The following four basic operations can be combined to copy and move

words and blocks.

1 Move a specified range to the copy buffer. (Cutting)

2 Copy a specified range to the copy buffer. (Copying)

3 Insert the contents of the copy buffer. (Pasting)

4 Use the contents of the copy buffer to create a new program.

(Pasting a program)

8.8.1 Basic Operations

Cutting

Procedure

(1) Position the cursor to the first word of the range to be moved.

(2) Press the [SELECT] soft key.

(3) Position the cursor and select the range to be moved, which is

displayed in white in reverse video.

(4) Press the [CUT] soft key.

Copying

Procedure

(1) Position the cursor to the first word of the range to be copied.

(2) Press the [SELECT] soft key.

(3) Position the cursor and select the range to be copied, which is

displayed in white in reverse video.

(4) Press the [COPY] soft key.

Pasting

Procedure

Method 1

(1) Position the cursor to the position at which the contents of

the copy buffer are to be inserted.

(2) Press the [PASTE] soft key.

(3) Press the [HERE] soft key.

The contents of the copy buffer are inserted ahead of the

cursor.

Method 2

(1) Position the cursor to the position at which the contents of

the copy buffer are to be inserted.
