Series 15i/150i - MA (Operation) Operators manual Page 251

Operators manual
8.EDITING PROGRAMS OPERATION B-63324EN-1/03
- 230 -
Registering multiple NC programs
Procedure
Method 1 (Neither the input file names nor numbers need be specified)
(1) Select EDIT mode.
(2) Follow the procedure described in Section II-10.1,
"Programs" to display the program text screen.
(3) Press the [READ] soft key.
(4) Press the [ALL] soft key.
Method 2 (The input files are specified with their file names)
(1) Select EDIT mode.
(2) Follow the procedure described in Section II-10.1,
"Programs" to display the program text screen.
(3) Press the [READ] soft key.
(4) Press the ["FILE NAME] soft key.
(5) Enter a file name.
(6) Press the [FILE NAME"] soft key.
(7) Press the [ALL] soft key.
Method 3 (The input files are specified with their file numbers (one of
two methods))
(1) Select EDIT mode.
(2) Follow the procedure described in Section II-10.1,
"Programs" to display the program text screen.
(3) Press the [READ] soft key.
(4) Press the [(FILE#)] soft key.
(5) Enter a file number.
(6) Press the [ALL] soft key.
Method 4 (The input files are specified with their file numbers (two of
two methods))
(1) Select EDIT mode.
(2) Follow the procedure described in Section II-10.1,
"Programs" to display the program text screen.
(3) Press the [READ] soft key.
(4) Press the address key.
(5) Enter a file number.
(6) Press the [ALL] soft key.
