Series 15i/150i - MA (Operation) Operators manual Page 326

Operators manual
B-63324EN-1/03 OPERATION 9.SETTING AND DISPLAYING DATA
- 305 -
Workpiece origin offset input/output
- Workpiece origin offset input
Method 1 (Neither the input file name nor number need be specified)
(1) Press the [READ] soft key.
(2) Press the [WORK OFFSET] soft key.
Method 2 (The input file is specified with its file name)
(1) Press the [READ] soft key.
(2) Press the ["FILE NAME] soft key.
(3) Enter a file name.
(4) Press the [FILE NAME"] soft key.
(5) Press the [WORK OFFSET] soft key.
Method 3 (The input file is specified with its file number (one of three
methods))
(1) Press the [READ] soft key.
(2) Press the [(FILE #)] soft key.
(3) Enter a file number.
(4) Press the [WORK OFFSET] soft key.
Method 4 (The input file is specified with its file number (two of three
methods))
(1) Press the [READ] soft key.
(2) Press the
N
address key.
(3) Enter a file number.
(4) Press the [WORK OFFSET] soft key.
Method 5 (The input file is specified with its file number (three of three
methods))
(1) Press the
N
address key.
(2) Enter a file number.
(3) Press the [READ] soft key.
- Workpiece origin offset output
Method 1(when neither an output file name nor a file number is
specified)
(1) Press the [PUNCH] soft key.
(2) Press the [WORK OFFSET] soft key.
Method 2 (The output file is specified with its file name)
(1) Press the [PUNCH] soft key.
(2) Press the ["FILE NAME] soft key.
(3) Enter a file name.
(4) Press the [FILE NAME"] soft key.
(5) Press the [WORK OFFSET] soft key.
