12.INPUTTING/OUTPUTTING DATA OPERATION B-63324EN-1/03

- 542 -

12.3 INPUTTING AND OUTPUTTING PROGRAMS

12.3.1 Outputting Programs

The following explains the operation for outputting the programs

registered in the memory of the CNC to a floppy disk.

Setup for output

(1) Select EDIT mode.

(2) Follow either of the procedures described below to display the

Program Text screen.

Method 1

Press the

PROG

function key several times, until the Program

Text screen appears.

Method 2

(1)

Press the

PROG

function key.

(2)

Press the [TEXT] soft key.

Outputting the currently displayed program

Method 1 (Neither the output file name nor number need be specified)

(1) Press the [PUNCH] soft key.

(2) Press the [THIS PROGRAM] soft key.

Method 2 (The output file is specified with its file name)

(1) Press the [PUNCH] soft key.

(2) Press the ["FILE NAME] soft key.

(3) Enter a file name.

(4) Press the [FILE NAME"] soft key.

(5) Press the [THIS PROGRAM] soft key.

Method 3 (Specified with its file number (one of two methods))

(1) Press the [PUNCH] soft key.

(2) Press the [(FILE#)] soft key.

(3) Enter a file number.

(4) Press the [THIS PROGRAM] soft key.

Method 4 (Specified with its file number (two of two methods))

(1) Press the [PUNCH] soft key.

(2) Press the

address key.

(3) Enter a file number.

(4) Press the [THIS PROGRAM] soft key.
