4.AUTOMATIC OPERATION OPERATION B-63324EN-1/03

- 130 -

5 Press the Cycle Start button. The moves to the machining restart

position at the dry run feedrate sequentially along axes in the

order specified by parameter setting No. 7110. Machining is then

restarted.

Procedure for Program Restart by Specifying a Block Number

Procedure 1

[ P TYPE ]

1 Retract the tool and replace it with a new one. When necessary,

change the offset. (Go to step 2.)

[ Q TYPE ]

1 When power is turned ON or emergency stop is released, perform

all necessary operations at that time, including the reference

position return.

2 Move the machine manually to the program starting point

(machining start point), and keep the modal data and coordinate

system in the same conditions as at the machining start.

3 If necessary, modify the offset amount. (Go to step 2.)

Procedure 2

[P TYPE]

1 Turn the program restart switch on the machine operator’s panel

ON.

2 Press key to display the desired program.

3 Find the program head.

4 Press the [PROGRAM RESTART] soft key then [(P_BLK#)]

soft key, enter the block number of the block you want to restart,

then press the [EXEC] soft key. (Go to step 3.)

PB x x x x x x x x [EXEC]

Block number

PROG
