B-63324EN-1/03 OPERATION 3.MANUAL OPERATION

- 75 -

- Automatic reference position return (G28)

The tool returns directly to the reference position without passing

through any intermediate points, regardless of the specified amount of

travel. For axes for which no move command is specified, however, a

return operation is not performed.

Feedrate (parameter) Rapid traverse rate (No. 1420)

Automatic acceleration/

deceleration (parameter)

Linear acceleration/

deceleration in rapid traverse for each

axis (No. 1620)

Override Rapid traverse override

- 2nd, 3rd or 4th reference position return (G30)

The tool returns directly to the 2nd, 3rd or 4th reference position

without passing through any intermediate points, regardless of the

specified amount of travel. To select a reference point, specify P2, P3

or P4 in address P. If address P is omitted, a return to the 2nd reference

position is performed.

Feedrate (parameter) Rapid traverse rate (No. 1420)

Automatic acceleration/

deceleration (parameter)

Linear acceleration/

deceleration in rapid traverse for each

axis (No. 1620)

Override Rapid traverse override

NOTE

The 2nd, 3rd or 4th reference position return function

is optional. If this option is not selected, the warning

"FORMAT ERROR" is generated, and G30 cannot be

entered. If neither of P2, P3 or P4 are specified in

address P when this option is selected, a "START

IMPOSSIBLE" warning is generated, and the entered

data cannot be executed.

- M codes (miscellaneous functions)

After address M, specify a numeric value of no more than the number

of digits specified by parameter No. 2030.

NOTE

Neither subprogram calls nor custom macro calls can

be performed using M codes.

- S codes (spindle functions)

After address S, specify a numeric value of no more than the number of

digits specified by parameter No. 2031.

NOTE

Subprogram calls cannot be performed using S codes.
