B-63324EN-1/03 OPERATION 10.DISPLAY

- 477 -

6 G60 (unidirectional positioning)

Drawing is always performed directly up to the specified

position, even if the positioning direction is opposite.

4. Functions that behave differently

1 G02.2/G03.2 (involute interpolation)

Circular interpolation is performed if parameter GST (bit 1

of No. 2207) is set to 0. A warning is displayed and drawing

stops if parameter GST is set to 1.

2 G06.1 (spline interpolation)

Linear interpolation is performed if parameter GST (bit 1 of

No. 2207) is set to 0. A warning is displayed and drawing

stops if parameter GST is set to 1.

3 G02.1/G03.1 (circular threading B)

Circular interpolation is performed. Drawing is not possible

with a rotation axis.

4 G02.3/G03.3 (exponential interpolation)

Linear interpolation is performed with a linear axis only.

5 G07 (hypothetical axis interpolation)

Circular interpolation is performed.

6 G07.1 (cylindrical interpolation)

Drawing is performed on a cylindrical expanded plane.

7 G12.1 (polar coordinate interpolation)

Drawing is performed in the Cartesian coordinate system on

a polar coordinate plane.

Functions that are not available during background drawing

If an attempt is made to execute the following functions, a warning is

displayed and drawing stops:

M198 External subprogram call

M10 Programmable data input

NOTE

Parameters/tool life management data data/tool

number offset data/volumetric compensation data

cannot be changed with G10.

The tool offset value/workpiece origin offset/extended

workpiece origin offset/macro variables/fixture offset

data can be changed. Only those items of data used

for background drawing can be changed; those items

of data used for ordinary automatic operation cannot

be changed.
