8.EDITING PROGRAMS OPERATION B-63324EN-1/03

- 260 -

8.6 CHANGING WORDS AND BLOCKS

1 The word at the cursor position can be overwritten with an entered

word or block.

2 A word, address, or character string in the program being edited

can be replaced.

8.6.1 Overwriting Words

Overwriting words

Procedure

(1) Position the cursor to the word to be overwritten.

(2) Key in a new word.

Multiple words and blocks can be entered until the key-in buffer

is full.

(3) Press the key.

Limitation

It is possible to replace a single word with multiple words or blocks.

The procedure described in this section cannot, however, replace

multiple words with a single word. To do this, see Section II-8.6.2,

"Replacing words and character strings."

ALTER
