Series 15i/150i - MA (Operation) Operators manual Page 304

Operators manual

Page of 628

/ 628

B-63324EN-1/03 OPERATION 8.EDITING PROGRAMS

- 283 -

8.16 EDITING PROGRAMS IN OPERATION

During automatic operation, programs can be edited by stopping

automatic operation with the feed hold or single block function.

Automatic operation can then be resumed.

Editing programs in operation

Procedure

(1) Stop automatic operation, using the feed hold or single block

function. Make a note of the cursor position.

(2) Enter EDIT mode to edit programs.

(3) Return the cursor to the previous position, which you noted in step

(1).

(4) Return to the previous operation mode to resume automatic

operation.

CAUTION

When resuming memory operation after program

editing, make sure that the cursor is placed at the

previous position. If the cursor is at the wrong

position, the program is not executed as displayed

on the screen after machining is resumed.

Limitation

The available editing operations depend on the type of the program that

is being operated.

1 If a main program is being operated

- All editing operations are available

2 If a subprogram is being operated

- If a subprogram is being operated

- Editing is possible only if the operation has been

memory operation.

- Editing is possible in word units only.
