B-63324EN-1/03 OPERATION 4.AUTOMATIC OPERATION

- 135 -

- Macro statement, macro call and subprogram call blocks

Macro statement, macro call and subprogram call blocks cannot be

searched even if they are prefixed with a sequence number. In this case,

try searching the previous block.

Alarm

Number Message Contents

SR0592 END OF RECORD The EOR (End of Record) code is specified in the middle of

a block.

This alarm is also generated when the percentage at the

end of the NC program is read.

This alarm is also generated when the specified block is not

found by the program restart function.

SR0600 PARAMETER OF RESTART

ERROR

An illegal value is set to parameter No. 7110 that specifies

the order in which axes move when machining is restarted

in the dry run.

The setting range is 1 to the number of controlled axes.

CAUTION

As a rule, the tool cannot be returned to a correct

position under the following conditions.

Special care must be taken in the following cases

since none of them cause an alarm:

- Manual operation is performed when the manual

absolute mode is OFF.

- When operation is performed with the machine

locked and Z-axis ignored.

- When the mirror image function is used. For the

block in which the mirror image function was turned

on or off most recently, as well as for subsequent

blocks, P-type return can be performed. In this

case, the mirror image signal must be held in the

same state as that observed at the time of

interruption.

- When no coordinate system is set at the beginning

of a program in which major commands are in

incremental mode.

- When manual operation is performed in the course

of axis movement for returning operation.

- When the program restart is commanded for a

block between the block for skip cutting and

subsequent absolute command block.

- The machine lock state is released after the

command for restarting the program is issued in

that state.

- When a coordinate system is set, changed, or

shifted after search operation terminates, the tool

cannot be returned to the correct position.
