12.INPUTTING/OUTPUTTING DATA OPERATION B-63324EN-1/03

- 576 -

12.12 OUTPUTTING SYSTEM CONFIGURATION DATA

12.12.1 Outputting System Configuration Data

The following explains the operation for outputting the system

configuration data registered in the memory of the CNC to a floppy

disk.

Setup for output

(1) Select MDI mode.

(2) Follow either of the procedures described below to display the

System configuration data screen.

Method 1

Press the

SYSTEM

function key several times, until the System

configuration data screen appears.

Method 2

(1) Press the

SYSTEM

function key.

(2) Press the [SYSTEM CONFIG] soft key.

Execution of output

Method 1 (Neither the output file name nor number need be specified)

(1) Press the [PUNCH] soft key.

(2) Press the [SYSTEM CONFIG] soft key.

Method 2 (The output file is specified with its file name)

(1) Press the [PUNCH] soft key.

(2) Press the ["FILE NAME] soft key.

(3) Enter a file name.

(4) Press the [FILE NAME"] soft key.

(5) Press the [SYSTEM CONFIG] soft key.

Method 3 (Specified with its file number (one of three methods))

(1) Press the [PUNCH] soft key.

(2) Press the [(FILE#)] soft key.

(3) Enter a file number.

(4) Press the [SYSTEM CONFIG] soft key.

Method 4 (Specified with its file number (two of three methods))

(1) Press the [PUNCH] soft key.

(2) Press the

address key.

(3) Enter a file number.

(4) Press the [SYSTEM CONFIG] soft key.
