Series 15i/150i - MA (Operation) Operators manual Page 391

Operators manual

Page of 628

/ 628

9.SETTING AND DISPLAYING DATA OPERATION B-63324EN-1/03

- 370 -

- Manual handle

Select the axis on which a movement is to be made with the first handle,

and also select a magnification.

- Override

Set an override value for the rapid traverse rate, jog feedrate, cutting

feedrate, and spindle speed.

- Automatic operation

Set optional block skip, single block, machine lock, and dry run.

- General-purpose switches

Eight general-purpose switches are available. A name not longer than

eight characters can be assigned to each switch. A named switch is

enabled. For the function of each switch, refer to the manual provided

by the machine tool builder.

Operating and setting the software operator’s panel

- Selecting a group

Select a group with [NEXT GROUP], [PREV GROUP], or the cursor

keys

. The group name of the selected group is displayed in

red.

- Selecting data

Select data with the cursor keys . A light blue cursor is

displayed in the data name and data selected.

- Setting data

Change data settings with the cursor keys . The override

values below can be set for the jog feedrate/cutting feedrate/spindle

speed.

Jog feedrate override

25 overrides: 0, 0.1, 0.14, 0.2, 0.27, 0.37, 0.52, 0.72, 1.0, 1.4, 2.0, 2.7,

3.7, 5.2, 7.2, 10, 14, 20, 27, 37, 52, 72, 100, 140, and 200%

Cutting feedrate override

21 overrides: 0, 10, 20, 30, 40, 50, 60, 70, 80, 90, 100, 110, 120, 130,

140, 150, 160, 170, 180, 190, and 200%

Spindle speed

21 overrides: 0, 10, 20, 30, 40, 50, 60, 70, 80, 90, 100, 110, 120, 130,

140, 150, 160, 170, 180, 190, and 200%
