POWER MATE i-MODEL D/H (FUNCTION) Connection manual (Function) Page 1013

Connection manual (Function)

Page of 1173

/ 1173

EDIT

DATE DESIG

DESCRIPTION

FANUC LTD

B-63173EN-1/01-28

DRAW.NO.

CUST

TITLE

FANUC Power Mate i -MODEL H

CONNECTION MANUAL(FUNCTION)

M-code direct output function

(High Response Function)

3/16

SHEET

1.8.2.3 Direct signal output function in high response function

In high response mode, the signals of the built-in I/O (Y1000-Y1002) can

be controlled directly by the M-code command of CNC.

• This function enables to turn on/off signals at high speed, because

signals can be input/output without passing through PMC .

• As for on/off timing of direct signals, there are two types of

controlling methods. One is immediate output type. Another type

is output after pulse distribution end. The preferable method can

be selected by the command.

For example, this function can be used as the following fig.1.

1) When the axis moved by G01 reaches near the point B, this function

turns on a direct signal. Then, another program is started, and the axis

of another path is started moving.

2) When the axis stops at the point C, this function turns on another direct

signal. Then, the program to terminate the operation is started.

1) This function turns on a direct

signal

near the point B.

2) This function turns on

another direct signal after

the axis stops at the point C.

Another program is started.

The program to terminate the

operation is started.

An axis is moved from A to B by way of C.

Fig.1

Add the following description after the chapter 1.8.2.2 “M99 in high speed response

modemode””..
