Replace the address part “A.1 List of Address” with the following list

#7 #6 #5 #4 #3 #2 #1 #0

F298 TDSML8 TDSML7 TDSML6 TDSML5 TDSML4 TDSML3 TDSML2 TDSML1

F299 TDFTR8 TDFTR7 TDFTR6 TDFTR5 TDFTR4 TDFTR3 TDFTR2 TDFTR1

Add the following list to “A.2.1 Signal Summary(in the order of functions) of “A.2 Signal summary”

Symbol Signal name Address PMi-D PMi-H Section

TDSML1～TDSML8 Thermal sumilation data

Trouble forecast signal

F298 ○ ○

TDFTR1～TDFTR8 Disturbance torque

Trouble forecast signal

F299 ○ ○

12.2.6

Add the following list to “A.2.2 Signal Summary(in the order of symbols) of “A.2 Signal summary”

Address Signal name Symbol PMi-D PMi-H Section

F298 Thermal sumilation data

Trouble forecast signal

TDSML1～TDSML8 ○ ○

F299 Disturbance torque trouble

Forecast signal

TDFTR1～TDFTR8 ○ ○

12.2.6

B-63173EN-1/01-36

Edit

Apprv.

Desig.

Sheet

Title

Draw

No.

4/4

Date

Design

Description

Date

FANUC Power Mate i –MODEL D/H

Trouble Diagnosis
